SQD 1804
Sublimation Printer
$44,995.00
/
The Arcus Squid-1804 roll-to-roll dye-sublimation printer is the ideal solution for
a wide variety of dye-sublimation applications. From apparel to promotional items, to banners and signage, the Squid-1804 can handle the most demanding production requirements with a print width of 72” and maximum production speeds of 1600 sq,ft./hr.
Industrial design for high-volume printing, the Squid-1804 features advanced heavy-duty media handling systems to allow for extended long runs with precision rewinds.
Arcus printers come with industry-leading training and customer support.
Specification
- Print Head: (4) Epson I3200
- Print Resolutions: 360 / 600 / 720 / 1200 / 1800 / 3600 dpi - 10 Modes
- Print Method: Variable DOD
- Ink Type: Aqueous / Pigment / Dye
- Ink Colors: CYMK White Varnish
- Ink Supply: Main Supply Tank and Secondary Sub Tank
- Ink Capacity: 1000mL / Bottle
- Max Media Width: 1900mm / 74.8 inches
- Media Type: Sublimation paper
- Media Take-Up: Intelligent Control Dual Power Wind/Unwind
- Media Supported: 50 kg / 110 lbs.
- Head Carriage Height: 1.5mm - 3.5mm Adjustable
- Head Cleaning / Capping: Automatic Lift / Auto-Clean
- In-Line Heater: Pre / Print / Post
- External Drying: IR+ Fan
- Screen Display: LED
- Data Interface: 1000M LAN
- Operating Temperature: 15°C - 30°C / 60°F - 90°F
- Operating Humidity: 40% - 60%
- Supported RIP: Ergosoft / Arcuslink
- Supported OS: Windows 7 /8 /10 /11
- Printer Voltage: AC 220V 50Hz / 60Hz (110V option)
- Printer Power Consumption: Standby 200W / Working 1600W
- Printer Amperage: 4.6A (220V) 9.1A (110V)
- Dryer Power Consumption: 8000W @ 220V 50 Hz - 60 Hz
- Ship Dimensions: 3300mm x 900mm x 750mm / 130" x 35" x 30"
- Ship Weight: 360 kg / 794 lbs.
- Machine Weight: 260 kg / 573 lbs.
PRINT SPEED - 4 Pass: 861 sq. ft./hr (80 sq. m/hr)
- 2 Pass: 1600 sq. ft./hr (160 sq. m/hr)
Downloads
Included
- Ergosoft Production RIP Software
- Training and Customer Support
- 1 Year Warranty
